Waveshare Dual ETH RS485 Mini-Computer based on CM4

DescriptionPackage content:CM4-ETH-RS485-BASE-B x1Metal case (top and bottom) x1Fan x112V 2A Power Supply x1Screwdriver x1Antenna connector rubber plug x1Screws pack x1Dual ETH Quad RS485 Computer Based On CM4Designed For Raspberry Pi Compute Module 4 Waveshare Dual ETH Quad RS485 Expansion Board InsideMake It Easy To Build Your Own Raspberry Pi CM4 Mini PCfor reference only, CM4 is NOT included.SpecificationsCM4 SOCKETsuitable for all variants of Compute Module 4NETWORKINGGigabit Ethernet RJ45 connector, 100M Ethernet RJ45 connectorUSBUSB 2.0 Type A × 2CONNECTORIsolated RS485 × 4, Power screw terminal × 1CAMERAMIPI CSI-2 port × 2 (15pin 1.0mm FPC connector)VIDEOHDMI port × 1, supports 4K 30fps outputRTCReal-time clock with battery socket and ability to wake Compute Module 4STORAGEMicroSD card socket for Compute Module 4 Lite (without eMMC) variantsFAN HEADERallows speed adjustment, 5VINDICATORPower indicator × 1, CM4 status indicator × 1, User LED × 2, RS485 communication indicator × 8POWER INPUT7-36VDIMENSIONS123 × 98 × 32mm More Rich InterfacesPrecise Cut-Out With Clear LabelEach Cut-Out Is Completely Aligned With The ConnectorCooling Fan IncludedComes With Cooling Fan, Combined With The Airflow Vent, Better Heat Dissipation Wall Mount SupportWall Mount Holes On Two Sides, Handy For MountingApplication ExamplesSuitable For Raspberry Pi Applications Requiring Multi-Channel RS485 Communication Or Other Industrial Contextfor reference only, display, cameras, and antenna are NOT included. Outline Dimensions
