Waveshare Industrial IoT Mini-Computer Based on CM4

DescriptionContents:Compute Module 4 PoE 4G Board x1Metal case (top and bottom) x1Fan-4010-PWM-12V x1Screwdriver x1Screws pack x112V 2A power adapter x1Industrial IoT Mini-Computer Based On CM4Designed For Raspberry Pi Compute Module 4Waveshare CM4 Industrial IoT Board Inside, Fast And Easy To Build A Mini-ComputerPart List ComparisonRAW BASE BOARDMINI-COMPUTER KITMINI-COMPUTER KIT 4G MODULECM4 Industrial IoT Board√√√Metal case√√5000rpm cooling fan√√12V 2A power adapter√√Screwdriver and screws√√4G module√Antenna√Antenna cable√Waveshare CM4 Industrial IoT Board InsideMake It Easy To Build Your Own Raspberry Pi CM4 Mini PCfor reference only, CM4 is NOT included. 4G module and antenna are optional.Base Board SpecificationsCM4 SOCKETsuitable for all variants of Compute Module 4NETWORKINGGigabit Ethernet RJ45 connector, integrates 802.3af-compliant PoE circuit (5V/2.5A)M.2 B KEY, supports 5G / 4G moduleSIM card slot, supports standard SIM card for 5G/4G/3G/2G communicationCONNECTORIsolated RS485, Isolated RS232, PCIe Gen 2 x1, I2C, ADC, GPIOUSBDual USB 2.0 Type ADISPLAYDual MIPI DSI display ports (15pin 1.0mm FPC connector)CAMERADual MIPI CSI-2 camera ports (15pin 1.0mm FPC connector)VIDEODual HDMI ports, supports 4K 30fps outputRTCReal-time clock with battery socket and ability to wake Compute Module 4STORAGEMicroSD card socket for Compute Module 4 Lite (without eMMC) variantsFAN HEADERallows speed adjustment and measurement, 5V / 12V inputPOWER INPUT7V~36V wide rangeDIMENSIONS160 × 114mmRich Peripheral ConnectorsOnboard Connectors Including M.2/CSI/DSI/HDMI/USB/ETH/PCIe/RS232/RS485Precise Cut-Out With Clear LabelEach Cut-Out Is Completely Aligned With The ConnectorCooling Fan IncludedComes With Cooling Fan, Combined With The Airflow Vent, Better Heat DissipationWall Mount SupportWall Mount Holes On Two Sides, Handy For MountingApplication ExamplesBinocular Vision, PoE Powered Raspberry Pi Projects, Or Other Industrial Contextfor reference only, displays, cameras, and antennas are NOT included.Outline DimensionsResources & ServicesWIKI: Compute_Module_4_PoE_4G_Board* Resources for different product may vary, please check the wiki page to confirm the actually provided resources.
